A new catalyst design created by U of T Engineering researchers could significantly improve the practicality of an electrochemical process that converts captured CO2 into multi-carbon molecules, which represent some of the key building blocks of the chemical industry.
“We need alternative routes to everyday products that do not require fossil fuel inputs,” says Professor David Sinton (MIE), senior author on a new paper published in Nature Energy.
“With recent advances in carbon capture, there is an opportunity to use CO2 to replace core chemical feedstocks on which the modern world relies. By developing cost-effective ways to upgrade this carbon into products we already need, we can increase the economic incentive to capture, rather than emit, CO2.”
One way to upgrade carbon involves electrochemistry, in which electricity is used to drive forward a desired chemical reaction. The conversion is carried out in devices known as electrolyzers, in which electrons combine with the reactants at the surface of a solid catalyst.
The team has a proven track record of successfully developing innovative ways to improve the efficiency of electrochemical CO2 conversion.
In their latest published work, the researchers focused on a variant of the process known as ‘cascade CO2 reduction.’ In this two-step process, CO2 is first dissolved in a liquid electrolyte, then passed through an electrolyzer, where it reacts with electrons to form carbon monoxide (CO).
The CO is then passed through a second electrolyzer where it is converted into two-carbon products such as ethanol, which is commonly used as fuel, and ethylene, which is a precursor to many types of plastics, as well as other consumer goods.
It is at this second step where the team found inefficiencies they believed could be overcome. These challenges were related to selectivity, which is the ability to maximize production of the target molecules by reducing the formation of undesirable side products.
“One of the key issues is the poor selectivity under low reactant availability,” says postdoctoral researcher Adnan Ozden (MIE PhD 2T2), one of four lead authors on the new paper.
“This, in turn, leads to a trade-off between the energy efficiency — meaning how efficiently we use the electrons we pump into the system — versus the carbon efficiency, which is a measure of how efficiently we use CO2 and CO.”
“There are ways to achieve high energy efficiency, and there are ways to achieve high carbon efficiency, but they are usually approached separately,” says former MIE postdoctoral fellow Dr. Jun Li, another of the lead authors, who is now an Associate Professor at Shanghai Jiao Tong University.
“Achieving both in a single-operation mode is the key.”
The team investigated the reasons for this trade-off and found that it originates from excessive accumulation of the positively charged ions, known as cations, on the catalyst surface, as well as the undesirable migration of the negatively charged ions, known as anions, away from the catalyst surface.
To overcome this challenge, they took inspiration from the design of supercapacitors, another electrochemical system where the transport of ions is critical. They added a porous material, known as a covalent organic framework, onto the surface of the catalyst, which enabled them to control the transport of cations and anions in the local reaction environment.
“With this modification, we obtained a highly porous, highly hydrophobic catalyst layer,” says Li.
“In this design, the covalent organic framework interacts with the cations to limit their diffusion to the active sites. The covalent organic framework also confines the locally produced anions due to its high hydrophobicity.”
Using the new catalyst design, the team built an electrolyzer that converts CO into two-carbon products with 95% carbon efficiency, while also keeping energy efficiency relatively high at 40%. This performance represents a new high-water mark in the design of such systems.
“When you look at what has been achieved so far in the field, the various approaches have tended to focus either on getting really high energy efficiency, or really high carbon efficiency,” says Ozden. “Our new design shows that it’s possible to break this trade-off.”
There is still more work to be done. For example, while the prototype device maintained its performance for more than 200 hours, it will need to last even longer if it’s to be used industrially. Still, the new strategy shows potential in terms of its ability to improve the value proposition of upgrading captured carbon.
“If this process is going to be adopted commercially, we need to be able to show that we can accomplish the conversion in a way that’s scalable and cost-effective enough to make economic sense,” says Sinton. “I think our approach demonstrates that this is a goal within reach.”
