A new study looks at how droplets expelled by a cough or sneeze can break up into smaller pieces when they collide with mask material. The research underscores the importance of multi-layer masks to prevent the spread of COVID-19. (Photo: CDC, via Unsplash)

An experimental study carried out by an international team of engineers and physicists has added more evidence for the value of triple-layer masking to prevent the spread of COVID-19 and similar diseases.

 “Any form of mask is better than no mask,” says Professor Swetaprovo Chaudhuri (UTIAS), one of the co-authors of a new paper published today in Science Advances.

 “But what we also show is that if they have enough momentum, large liquid droplets can penetrate single or even double-layer masks. When they do, they break up into smaller droplets that are more persistent in the air.”

 The team — which also includes Professor Abhishek Saha at the University of California San Diego, and Professor Saptarshi Basu of the Indian Institute of Science — is leveraging expertise they developed while studying aircraft engines. They use computer models and physical experiments to understand finely dispersed droplets in air, known as aerosols.

 In two previous papers, the team used models to describe the ways that droplets and aerosols created by a cough or sneeze can travel and persist in air. These mechanisms were then incorporated to develop a disease spread modelthe first one to be developed from the flow physics of transmission.

 In the latest paper, they used a device known as a droplet dispenser to fire liquid droplets at a piece of material from single-, double- and triple-layer masks.

Learn more about the experiment in this video, created by the authors for the 73rd annual meeting of the APS Division of Fluid Dynamics. (Authors: Shubham Sharma, Roven Pinto, Abhishek Saha,  Swetaprovo Chaudhuri, Saptarshi Basu)

The liquid used by the team was not real saliva but rather a facsimile made of water, salt and various proteins. The mask material was ordinary fabric with an average pore size of 30 micrometres, about the width of a human hair. Specialized cameras were used to take microscopic images up to 20,000 times per second to observe what happened.

 “A pore size of 30 micrometres can easily stop large solid particles that aren’t travelling too fast, but liquid droplets are a different story,” says Chaudhuri. “Liquids can deform, and big droplets can break up into smaller droplets, which have different characteristics.”

 Chaudhuri says that liquid droplets larger than 100 micrometres in diameter don’t usually spread very far, because they quickly drop to the ground via gravity. But droplets smaller than 100 micrometres wide form aerosols, which can persist in the air for much longer. The time period ranges from a few seconds in the case of those with diameters near 100 micrometres, to hundreds of hours for those near 10 micrometres.

 The team’s experiments showed that when droplets larger than 250 micrometres were fired at a single layer mask, they atomized, breaking up into pieces small enough to penetrate the material and form aerosols. This also happened with double-layer masks, but the proportion of pieces that made it through was only about 9%, compared with about 70% with the single-layered mask. Triple-layer masks were enough to stop virtually all the droplets.

The diagram in A shows how larger, high-velocity liquid droplets can break up into smaller ones when they collide with mask material. The photographs in B demonstrate how double- and triple-layer masks prevent transmission of these secondary droplets. (Image: Shubham Sharma and Roven Pinto)
The diagram in A shows how larger, high-velocity liquid droplets can break up into smaller ones when they collide with mask material. The photographs in B demonstrate how double- and triple-layer masks prevent transmission of these secondary droplets. (Image: Shubham Sharma and Roven Pinto)

Chaudhuri is quick to point out that little is known about the fate of the aerosols created by the atomization process. More research is needed to determine whether they could carry enough viral material to be infectious or how far they could travel.

Still, the findings provide more experimental evidence for what public health agencies around the world are recommending: any mask is better than no mask, but the more layers, the better.

Furthermore, fitting and leakage are very important issuesAn N95 is best, but if that is not available, the latest recommendation is a cloth mask supplemented with medical procedure mask,” says Chaudhuri. “The combined effect of procedural and well fitted cloth masks provide good filtration while reducing leakage

 While previous studies have looked at how droplets leak from the sides of masks, they typically have not captured how the mask itself can play a role in atomization.

 “Most studies also don’t look at what is going on at the individual droplet level and how aerosols can be generated,” Basu adds.

 This finding underlines the importance of a physics-based approach.

 “When we study combustion and sprays and the turbulent flows involving them as in aircraft engines, we think about droplets and aerosols a lot, from a lot of different angles,” says Chaudhuri. “I think there’s great value in bringing these perspectives to bear on the challenge of COVID-19, which affects us all.”
